5dBi High-gain 868MHz Antenna

C&T RF Antennas Inc - 5dBi High-gain 868MHz Antenna

High-gain 868MHz Antenna Manufacturer

C&T RF Antennas Inc is a Fiberglass Antenna 5dBi High gain 868MHz Antenna Manufacturer, we provide 868Mhz Antenna with many antenna types.

Contact the C&T RF sales team for more 868Mhz Antenna details.

What is a 5dBi High-gain 868MHz Antenna?

The High-gain 868MHz Antenna Omnidirectional antenna CTRF-ANTENNA-FB-0868-20260-N antenna style is an 868 MHz 5dBi Fiberglass Omni Antenna with N-male, grey color waterproof antenna mast outdoor antenna manufactured by C&T RF Antennas Inc.

The 868 MHz 5dBi FRP antennas provide 360-degree omnidirectional coverage for ISM/Lora bands.

Fiberglass Omnidirectional antennas description

Fiberglass Omnidirectional antennas are collinear designs enclosed in high-density fiberglass, which is covered with a protective ultraviolet-inhibiting coating.

The radiating elements are made from high-efficiency copper and are carefully phased to provide maximum gain in the horizontal plane. The mounting sleeves are tuned to eliminate RF currents from the transmission line, resulting in a “cold” sleeve allowing great freedom in mounting.

This high-quality and well-focused beam provides the highest gain and best efficiency.

The 5dBi Omnidirectional antenna High-gain 868MHz Antenna is manufactured by C&T RF Antennas Inc, the 868Mhz antenna manufacturer in China, we also provide other antenna types such as Through-hole Mount AntennasMagnetic Mount AntennasRubber Duck AntennasFiberglass AntennasPCB AntennasFPC AntennasSpring Antennas, etc.

C&T RF Antennas Inc provides the internal-external IoT & M2M antenna with many radio frequency bands such as Cellular6G5G4G3GNB-IoTGNSSGPSDual-band Wifi5.8 GHz2.4 GHz169MHz230MHz315MHz433MHz868MHz915MHz LoRaUWBRFIDADS-B, etc.

C&T RF Antennas Inc provides single-band, dual-band, and multi-band antennas for Wi-Fi And BluetoothGPS And GNSSLoRa And ISMIoT, And M2M applications.

Contact us for the 5dBi 868 Mhz antenna datasheet, 5dBi 868 Mhz antenna pricing, and 5dBi 868 Mhz antenna inventory.

Or other Lora ISM band 868Mhz antenna details.

5dBi High-gain 868MHz Antenna Specifications

5dBi 868MHz Antenna Electrical Specifications

RF Antenna TypeOmnidirectional Antenna
ModelCTRF-ANTENNA-FB-0868-20260-N
Frequency868 MHz
Gain5dBi
VSWR≤1.8
Impedance50 Ω
PolarizationVertical
DirectionalOmni-directional
ConnectorN-type Male
Max Power50W
Lightning ProtectionDC-Ground

5dBi 868MHz Antenna Mechanical Specifications

Antenna Dimension20*260mm
WeightApprox. 220g
Radome MaterialGlass Fiber
Operation Temperature-20˚C ~ +85˚C
Storage Temperature-40˚C ~ +85˚C
ColorGrey
Antenna DesignDipole Array
MountingScrew
Safety Emission and otherRoHS Compliant
ApplicationsPublic Safety/LMR/P25/TETRA, ISM/SCADA/Utilities, RFID, IoT/NB-IoT/LoRa

Fiberglass antenna features and applications

Omnidirectional Antenna FRP Antenna Features
Omnidirectional Antenna FRP Antenna Features  – C&T RF Antennas Inc
Omnidirectional Antenna Fiberglass Antenna Features
Omnidirectional Antenna Fiberglass Antenna Features  – C&T RF Antennas Inc
Fiberglass Antenna Mounting Methods
Fiberglass Antenna Mounting Methods  – C&T RF Antennas Inc



High-gain Omnidirectional Antenna Fiberglass Antennas
High-gain Omnidirectional Antenna Fiberglass Antennas  – C&T RF Antennas Inc



Omnidirectional Antenna Fiberglass Antenna Applications
Omnidirectional Antenna Fiberglass Antenna Applications  – C&T RF Antennas Inc
