What is a High-performance Internal FPC 3G 4G Antenna?
The High-performance Internal FPC 3G 4G Antenna CTRF-ANTENNA-FPC-7027-5060-IPEX bulti-in flexible PCB antenna 3G 4G LTE antenna is supplied by C&T RF Antennas Inc, a China RF antenna manufacturer.
The CTRF-ANTENNA-FPC-7027-5060-IPEX bulti-in antenna High-performance 3G 4G Internal FPC Antenna comes with a flexible circuit board 50x60mm antenna, covering 698-960MHz, 1710-2700MHz full-band 2G 3G 4G LTE frequency.
It has a 120mm length RG1.13 cable (cable length can be customized), Ipex / MHF / U.FL connector, 3M type directory mounts to the smart device for the ISM/SCADA/Utilities, IoT/NB-IoT/LoRa, 2G/3G/4G/LTE/LTE-IoT applications.
The High-performance 3G 4G Internal FPC Antenna is provided by C&T RF Antennas Inc, the RF antenna manufacturer in China, we provide many antenna types such as Through-hole Mount Antennas, Magnetic Mount Antennas, Rubber Duck Antennas, Fiberglass Antennas, PCB Antennas, FPC Antennas, Spring Coil Antennas, Sector Antenna, Yagi Antenna, etc.
C&T RF Antennas Inc provides the RF antenna with many antenna frequency bands such as Cellular, 6G, 5G, 4G, 3G, NB-IoT, GNSS, GPS, Dual-band Wifi, 5.8 GHz, 2.4 GHz, 169MHz, 230MHz, 315MHz, 433MHz, 868MHz, 915MHz LoRa, UWB, RFID, ADS-B, etc.
C&T RF Antennas Inc provides RF wireless antennas for Wi-Fi And Bluetooth, GPS And GNSS, LoRa And ISM, IoT, And M2M applications.
Contact the C&T RF team for more High-performance Internal FPC 3G 4G Antenna details such as 3G 4G flexible PCB antenna datasheet, 3G 4G flexible PCB antenna price, and 3G 4G flexible PCB antenna inventory.
Or other 3G 4G flexible PCB antenna styles.
High-performance Internal FPC 3G 4G Antenna Specifications
High-performance Internal FPC 3G 4G Antenna Electrical Specifications | |
| RF Antenna Type | Embedded FPC Antenna |
| Model | CTRF-ANTENNA-FPC-7027-5060-IPEX |
| Frequency | 700-960MHz, 1710-2700MHz |
| Gain | 3dBi/5dBi |
| VSWR | ≤2.0 |
| Impedance | 50 Ω |
| Polarization | Vertical Polarization |
| Cable Type | RG1.13 |
| Connector | U.FL/IPEX |
| Cable Length | 120mm |
| Lightning Protection | DC-Ground |
High-performance Internal FPC 3G 4G Antenna Mechanical Specifications | |
| FPC Board Dimension | 50*60mm |
| Weight | Approx. 6g |
| Material | Flexible PCB |
| Operation Temperature | -40˚C ~ +85˚C |
| Storage Temperature | -40˚C ~ +80˚C |
| Color | Black |
| Antenna Design | Dipole Array |
| Mounting | Connector/Sticker |
| Safety Emission and other | RoHS Compliant |
| Applications | ISM/SCADA/Utilities, IoT/M2M/NB-IoT/LoRa, 2G 3G 4G LTE/LTE-IoT/LTE-M/LTE-Cat, GSM GPRS UMTS PCS, etc. |
What is a Flexible circuit board antenna?
With the continuous high technology of smart wearable devices, what aspects of flexible circuit boards should continue to innovate in the future?
1. Flexible circuit board antenna thickness
The thickness of the flexible circuit board must be more flexible and must be thinner;
2. Folding resistance
The ability to bend is an inherent characteristic of flexible circuit boards. In the future, FPCs must be more resistant to folding, exceeding 10,000 times. Of course, this requires a better substrate;
3. Flexible circuit board antenna price
The price of flexible circuit boards is similar to PCBs. If the price of FPC comes down, the market will definitely be much broader.
4. The level of craftsmanship
In order to meet various requirements, the process of flexible circuit boards must be upgraded, and the minimum aperture and minimum line width/line distance must meet higher requirements.
Internal FPC 3G 4G Antenna Flex PCB Antenna Features
