What is a Lora Fiberglass Antenna 860-930MHz 5dBi?
The Lora Fiberglass Antenna 860-930MHz 5dBi CTRF-ANTENNA-FB-8693-20260-N is a Fibreglass LoRa antenna with a high-gain of 5dBi Lora 860-930MHz frequency range and 26cm length Omni antenna manufactured by C&T RF Antennas Inc for outdoor Lora & ISM networks.
The Lora Fiberglass Antenna 860-930MHz 5dBi has an IP67-rated waterproof glass fiber antenna mast, durable, dust-proof, and UV-proof functional high-performance Lora Fiberglass Outdoor Antenna.
How can LoRa systems be tested for mass production?
There are three important parameters to test in volume production: frequency tolerance, output power, and sensitivity. Frequency and output power are easy to test using a spectrum analyzer.
If your signal generator cannot generate a LoRa signal, it is highly recommended to test the sensitivity using FSK mode. There is only one RF link in the chip, and both FSK and LoRa are modulated in the digital domain.
The RF path can be assembled incorrectly (e.g., false soldering), so verification is important. The digital part of the chip LoRa and FSK modulation is not affected by the assembly, so for verification of production test performance test, FSK sensitivity is sufficient.
How do I choose the right crystal for my LoRa device?
Normally, for most designs with a bandwidth of 62.5kHz or higher, a +/-10ppm XTAL is sufficient. For bandwidths less than 62.5kHz, a TCXO is highly recommended.
For more detailed information on crystal specifications, please refer to the datasheet and the LoRa Modem Calculator Tool and Application Notes – AN1200.14_XO_Gidance_LoRa_Modulation_STD”.
The External Lora Fiberglass Antenna 860-930MHz 5dBi is manufactured by C&T RF Antennas Inc, the Lora internal antennas & Lora external antennas manufacturer in China.
C&T RF Antennas Inc provides the 15dBi Lora antenna, 11dBi Lora Antenna, 12dBi Lora antenna, 20dBi Lora antenna, 10dBi Lora antenna, 9dBi Lora antenna, 8dBi Lora antenna, 6dBi Lora antenna, 5.8dBi Lora antenna, 5dBi Lora antenna, 4dBi Lora antenna, 3dBi Glass Fiber Lora Antenna, 3dBi Lora antenna, 2.5dBi Lora antenna, 2dBi Lora antenna, etc.
C&T RF Antennas Inc provides Lora antennas with other antenna types such as Through-hole Mount Antennas, Magnetic Mount Antennas, Rubber Duck Antennas, Fiberglass Antennas, PCB Antennas, FPC Antennas, Spring Antennas, etc.
The Lora Fiberglass Antenna 860-930MHz 5dBi is available at C&T RF Antennas Inc. C&T RF Antennas Inc offers Lora Fiberglass Antenna 860-930MHz 5dBi inventory, Lora Fiberglass Antenna 860-930MHz 5dBi pricing, Lora Fiberglass Antenna 860-930MHz 5dBi datasheets or the other Lora antenna types.
Lora Fiberglass Antenna 860-930MHz 5dBi Specifications
Lora Fiberglass Antenna 860-930MHz 5dBi Electrical Specifications | |
| RF Antenna Type | Omni Fiberglass Antenna |
| Model | CTRF-ANTENNA-FB-8693-20260-N |
| Frequency Center | 860-930 MHz |
| Gain | 5 dBi |
| VSWR | ≤1.8 |
| Impedance | 50 Ω |
| Polarization | Vertical |
| Directional | Omni-directional |
| Connector | N-type Male |
| Max Power | 50W |
| Lightning Protection | DC-Ground |
Lora Fiberglass Antenna 860-930MHz 5dBi Mechanical Specifications | |
| Dimension | 20*260mm |
| Weight | Approx. 220g |
| Radome Material | Fiberglass |
| Operation Temperature | -20˚C ~ +85˚C |
| Storage Temperature | -40˚C ~ +85˚C |
| Color | Grey |
| Antenna Design | Dipole Array |
| Mounting | Screw |
| Safety Emission and other | RoHS Compliant |
| Applications | Public Safety/LMR/P25/TETRA, ISM/SCADA/Utilities, RFID, IoT/NB-IoT/LoRa |
Fiberglass antenna features and applications
How do you mount a LoRa antenna?
