High-performance 4 dBi NB-IoT External Antenna

13x190mm NB-IoT Antenna SMA NB-IoT External Antenna Manufacturer - C&T RF Antennas Inc

4dBi NB-IoT External Antenna Manufacturer

C&T RF Antennas Inc is the rubber duck antenna High-performance 4 dBi NB-IoT External Antenna manufacturer, we provide the NB-IoT antenna with other antenna types or other antenna frequencies.

Contact the C&T RF sales team for more High-performance 4 dBi NB-IoT External Antenna details.

What is a High-performance 4 dBi  NB-IoT External Antenna?

The High-performance 4 dBi NB-IoT External Antenna style CTRF-ANTENNA-AP-8221-13190-SMA antenna item is an SMA Connector or Terminal Mount rubber ducky antenna 13x190mm NB-IoT antenna manufactured by C&T RF Antennas Inc for 2G, 3G, GSM, NB-IoT, LTE M applications for IoT & M2M industries.

The Omni external NB-IoT antennas cover the rubber duck antenna, fiberglass antenna, through-hole mount antenna, magnetic mount antenna, etc.

For internal NB-IoT antenna covers the PCB antenna, flexible PCB antenna, spring antenna, chip antenna, etc.

NB-IoT process

In the 3GPP standard development, a typical process of adding a new technique is to first set up a-Si, and the technical report is derived through research projects. Related work is established in the same Release version or the next release version according to the research results of the technical report. The project, through the output of technical standards.

In the research project of GERAN group “FS_IOT_LC”, three technologies have been proposed, namely: extended overlaid GSM technology EC-GSM (Extended Coverage-GSM), NBCIoT technology, and NB-LTE technology.

Among them, NB-CIoT was jointly proposed by Huawei, Qualcomm, and Neul (Neul as British IoT, in September 2014), and NB-LTE was jointly proposed by Ericsson, ZTE, Nokia, and other manufacturers, eventually in September 2015. The Ran # 69 Plenary Session has been discussed, and finally negotiated is a technical solution, namely NB-IoT.



The High-performance 4 dBi NB-IoT External Antenna Rubber Duck Antenna is supplied by C&T RF Antennas Inc, a professional indoor-outdoor antenna manufacturer in China.

C&T RF Antennas Inc provides different antenna types such as Through-hole Mount AntennasMagnetic Mount AntennasRubber Duck AntennasFiberglass AntennasPCB AntennasFPC AntennasSpring Coil AntennasSector AntennasYagi antennas, etc.

C&T RF Antennas Inc provides the internal-external antenna with many radio frequency bands such as Cellular6G5G4G3GNB-IoTGNSSGPSDual-band Wifi5.8 GHz2.4 GHz169MHz230MHz315MHz433MHz868MHz915MHz LoRaUWBRFIDADS-B, etc.

C&T RF Antennas Inc provides single-band, dual-band, and multi-band antennas such as 3in1 combination antennas 4G/GPS/Wifi antennas, 2in1 4G/GPS antennasGSM/GPS antennas4G/Wifi antennasGPS/Wifi antennas, etc. for Wi-Fi And BluetoothGPS And GNSSLoRa And ISMIoT, And M2M applications.

Contact us for more High-performance 4 dBi NB-IoT External Antenna Rubber Duck Antenna details such as High-performance 4 dBi NB-IoT External Antenna datasheet, High-performance 4 dBi NB-IoT External Antenna pricing, antenna inventory, or other Narrowband IoT Antenna styles.

High-performance 4 dBi NB-IoT External Antenna Specifications

High-performance 4 dBi NB-IoT External Antenna Electrical Specifications

RF Antenna TypeRubber Duck Antenna
ModelCTRF-ANTENNA-AP-8221-13190-SMA
Frequency Center824-960MHz; 1710-2170MHz
Gain4dBi
VSWR≤2.0
Impedance50 Ω
PolarizationVerticle
DirectionalOmnidirectional
ConnectorSMA Male
Max Power50W
Lightning ProtectionDC-Ground

High-performance 4 dBi NB-IoT External Antenna Mechanical Specifications

Dimension13*190mm
WeightApprox. 18g
Radome MaterialPlastic TPEE
Operation Temperature-20˚C ~ +80˚C
Storage Temperature-40˚C ~ +85˚C
ColorBlack
Antenna DesignDipole Array
MountingSMA Connector
SafetyEmission and otherRoHS Compliant
ApplicationsISM/SCADA/Utilities, IoT/NB-IoT/LoRa, LTE-M/Cat-M, 2G/3G/GSM

High-performance 4 dBi NB-IoT External Antenna Rubber Duck Antenna Features

How to select your wifi router smart device connector
How to select your wifi router smart device connector – C&T RF Antennas Inc



Omnidirectional antenna rubber ducky antenna swivel antenna features
Omnidirectional antenna rubber ducky antenna swivel antenna features – C&T RF Antennas Inc



The Omni dipole antenna rubber duck antenna can be used with an antenna extension pigtail
The Omni dipole antenna rubber duck antenna can be used with an antenna extension pigtail – C&T RF Antennas Inc



High-performance 4 dBi NB-IoT External Antenna Rubber Ducky Antenna Applications
