What is 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna?
The Omni Antenna 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna CTRF-ANTENNA-FB-8593-20260-NM is an Omni fiberglass antenna 5dBi waterproof antenna 20x260mm size and an 868/915MHz glass fiber Lora antenna manufactured by C&T RF Antennas Inc.
The 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna fiberglass antenna is robust enough to withstand the harsh outdoor environment for IoT LPWAN Lora LoraWan applications.
The 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna is manufactured by C&T RF Antennas Inc, the Lora internal antennas & Lora external antennas manufacturer in China.
C&T RF Antennas Inc provides the 15dBi Lora antenna, 11dBi Lora Antenna, 12dBi Lora antenna, 20dBi Lora antenna, 10dBi Lora antenna, 9dBi Lora antenna, 8dBi Lora antenna, 6dBi Lora antenna, 5.8dBi Lora antenna, 5dBi Lora antenna, 4dBi Lora antenna, 3dBi Glass Fiber Lora Antenna, 3dBi Lora antenna, 2.5dBi Lora antenna, 2dBi Lora antenna, etc.
C&T RF Antennas Inc provides LoRa Wan antennas with many antenna types such as Through-hole Mount Antennas, Magnetic Mount Antennas, Rubber Duck Antennas, Fiberglass Antennas, PCB Antennas, FPC Antennas, Spring Coil Antennas, Sector Antennas, Yagi antennas, etc.
C&T RF Antennas Inc provides the internal-external antenna with many radio frequency bands such as Cellular, 6G, 5G, 4G, 3G, NB-IoT, GNSS, GPS, Dual-band Wifi, 5.8 GHz, 2.4 GHz, 169MHz, 230MHz, 315MHz, 433MHz, 868MHz, 915MHz LoRa, UWB, RFID, ADS-B, etc.
C&T RF Antennas Inc provides single-band, dual-band, and multi-band antennas such as 3in1 combination antennas 4G/GPS/Wifi antennas, 2in1 4G/GPS antennas, GSM/GPS antennas, 4G/Wifi antennas, GPS/Wifi antennas, etc. for Wi-Fi And Bluetooth, GPS And GNSS, LoRa And ISM, IoT, And M2M applications.
The Omni 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna is available at C&T RF Antennas Inc.
Contact us for the 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna inventory, 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna pricing, & 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna datasheets, or the other Lora antennas.
5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna Specifications
5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna Electrical Specifications | |
RF Antenna Type | Omni Fiberglass Antenna |
Model | CTRF-ANTENNA-FB-8593-20260-NM |
Frequency Range | 850-930MHz |
Gain | 5dBi |
VSWR | ≤1.8 |
Impedance | 50 Ω |
Polarization | Vertical |
Directional | Omni-directional |
Connector | N-type Male |
Max Power | 50W |
Lightning Protection | DC-Ground |
5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna Mechanical Specifications | |
Dimension | 20*260mm |
Weight | Approx. 220g |
Radome Material | Fiberglass |
Operation Temperature | -20˚C ~ +85˚C |
Storage Temperature | -40˚C ~ +85˚C |
Color | Grey |
Antenna Design | Dipole Array |
Mounting | Screw |
Safety Emission and other | RoHS Compliant |
Applications | Public Safety/LMR/P25/TETRA, ISM/SCADA/Utilities, RFID, IoT/NB-IoT/LoRa |
What is LoRaWAN network architecture?
The LoRaWAN network architecture is a typical star topology in which a LoRa gateway is a transparent transmission relay connecting end devices to a central server at the back end.
The LoRaWAN gateways are connected to the server via a standard IP connection and the end devices communicate with one or more gateways using a single hop. All nodes communicate bi-directionally with the gateways and also support operations such as cloud upgrades to reduce cloud communication time.
What is LoRaWAN adaptive rate?
Communication between LoRaWAN endpoints and gateways is done on the basis of different frequencies and data rates, which are chosen in the trade-off between transmission distance and message latency.
Thanks to spreading spectrum technology, communications at different transmission rates do not interfere with each other and a “virtualized” set of frequency bands is created to increase the gateway’s capacity.
The LoRaWAN data rates range from 0.3 kbps to 37.5 kbps. To maximize the battery life of the end devices and the overall network capacity, the LoRaWAN web server controls the data rate and the RF output power of each end device through an Adaptive Data Rate (ADR) scheme.
What is LoRaWAN device encryption?
For any LPWAN, incoming encryption is extremely important and LoRaWAN utilizes two layers of encryption, the network layer, and the application layer.
Network layer encryption ensures that nodes are authenticated in the network, and application layer encryption ensures that node network operations do not access end-user application data. An IEEE EU164 discriminator is used as AES encryption during key exchange.
There are trade-offs for each technology choice, but LoRaWAN is optimized for a wide range of IoT applications in terms of network architecture, device type, encryption, capacity, and mobile addressing.
LoRaWAN specifications vary slightly from region to region, based on the frequency bands and regulatory requirements allowed in different regions.
LoRaWAN specifications have been developed for Europe and North America, but other regions are still being developed by technical committees.
Joining the LoRa Alliance as a contributor member and participating in technical committees can provide access to critical company solutions for the Asian market.
LPWAN technology options comparison
There is a lot of activity in the IoT space comparing LPWAN options, not only in terms of technology comparisons but also in terms of business model observations.
LPWAN networks are being deployed because there are strong business reasons to support immediate deployment and the cost of deployment over unlicensed channels is far less than 3G software updates. Questions that need to be answered before comparing different LPWAN technologies are
Flexibility to build a large and diverse application
Whether the communication protocol is encrypted or not
Technical aspects, range, capacity, two-way communication, robustness against interference
Network deployment overheads, end node BOM overheads, battery overheads
Ecosystem solutions required for a flexible business model
End product availability to ensure ROI of network deployment
Strength of ecosystem to ensure longevity and quality of solution
5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna Fiberglass antenna features and applications
How do you mount a 5dBi Lora Antenna Outdoor Fiber Glass Lorawan Antenna?
